Description
=======================================================================================================================
Welcome To Our Store!
-
If you are going to region an order, please leave a message on the order page.
-
About the lens focal length, plug specification, and you wish to declare how lots value(Only high value goods need,This will keep away from more tariffs for you).
-
For example: 6mm lens, European plug, declare $120
-
Thanks for your guide,We will give you the best service
=======================================================================================================================
Anran Security Network IP Camera
Model
Brand Name
Anran Security
Model Number
AR-36169-IP2.0
Style
Bullet Camera
Camera
Processor
Hi3516C
Sensor Type
1/2.5" SONY CMOS Sensor Progressive Scan
Effective pixels,Resolution
2.0 Megapixel 1920×1080 (1080P) 25Fps
Lens
The default 4mm(6mm,8mm,12mm For Optional)
Focal length
2.8mm
3.6mm
4mm
6mm
8mm
12mm
16mm
Viewing Attitude
89.7°
75.7°
69.9°
50°
38.5°
26.2°
19.8°
Suitable for distance
0-2M
0-3M
3-5M
5-10M
10-20M
20-35M
35-50M
Infrared Light
36 IR Leds.IR Range 15-20m
Day and Night Switch Mode
Auto, dual IR-Cut filter
Min.Illumination
Colour zero.01 Lux,F1.2,B/W zero.001 Lux,F1.2 (The night vision effect is very good.)
Max S/N Ratio
39dB
Video Encoding
Video Compression
H.264 Main Profile; AVI Baseline
Main Stream
FHD 1920*1080P 1-25fps
Video Bitrate
0.1Mbps~6Mbps,Supports CBR/VBR
Functions
Title OSD
Supports Channel name, Date, And video stream assistance overlay
Privacy Mask
4 Configurable Regions
Special aspects
Auto Exposure Control (AEC); Auto White Balance (AWB);
Auto Band Filter (ABF); Auto Black Level Calibration (ABLC); Support digital WDR
Intelligent Alarm
Video Motion,Video Blind,Video Loss
Alarm Way
Email Alarm or FTP
Image Orientation
Image Flip and Mirror
Network protocol
TCP/IP UDP RTP RTSP RTCP HTTP DNS DDNS DHCP FTP NTP PPPOE SMTP UPNP
ONVIF protocols
Support 2.0 Version
Recording
Recording set up to record by motion trigger, alarm trigger, manual, or schedule
Remote View
IE 6.0 or later, firefox
Interface
Network Interface
10/100M BASE-TX,RJ-45 connector
General Specifications
Operating Temperature
-20°C~50°C (-4°F ~ 122°F)
Operating Humidity
0% -85% RH
Power Supply
DC12V 2.0A(Provide correct for local use plug)
Power Consumption
9W (MAX)
Waterproof / Weatherproof
Yes
Appearance material
Metal
Weight
0.95kg
NVR6008T-PL:8*1080P/8*720P/16*D1, 30fps 1080P decoding
System
Model
NVR6008T-PL
Main Processor
1 X HI3520A
Operating System
Embedded LINUX
System Resources
Pentaplex Function:Live,Recording,Playback,Backup & Remote access
Preview
1/4/9
Control Device
Front Panel,USB Mouse,IR Remote Control
Video
Video Standards
PAL 625 line,50F/s;NTSC 525 line,60F/s
Video Compression
H.264 High Profile
Video Recording
1080P:PAL 1Fps/s-25Fps/s; NTSC 1Fps/s-30Fps/s;
Motion Detection
Zones:396(22*18)Detection Zones,Sensitivity:1-6(6 is Highest)
Trigger recording,PTZ movement,Tour,Alarm,E-mail& FTP
TV Output Adjustment
Adjust TV Output Color & Display Zone
Audio
Audio Compression
G711A
Bidirectional Talk
Not Guide
Record Playback
Recording Mode
Manual>Alarm>Video Detection>Timing
Playback
1080P:1 or 2 CH ;720P:4 CH
Pause,Stop,Rewind,Fast Play,Slow Play,Next File,Previous File,
Repeat,Shuffle,Backup Selection
Search Mode
Time/Date, Alarm, Motion Detection & Exact Search (accurate to second)
Storage Backup
Space Occupation
Video:1080P forty-50G/day/ch,720P 20-25G/day/ch,
D1 10~15G/day/ch ; Audio: 691.2M/day/ch
HDD Management
Hard Disk Hibernation Technology, HDD Faulty Alarm & Raid (Redundancy)
Backup Mode
Network Backup / Usb Mobile Hard Disk
Interface
Video Input
N/A
Video Output
1CH VGA Output, 1Ch HDMI Output
Audio Input
N/A
Audio Output
N/A
Alarm Input
N/A
Relay Output
N/A
Net Interface
RJ-45 10M/100M
PTZ Control
1 RS485
3G/WIFI
Support(usb extension)
USB Interface
2* USB2.0 Port for Mouse and Backup
Hard Disk
1 SATA port (Max 1 x 3T)
Environmental
Power Supply
12V/3A
Power Consumption
<10W
Working Temperature
0-55
Working Humidity
10%-90%
Atmosphere Pressure
86kpa-106kpa
Dimension
255mm*225mm*45mm
Weight
1.8KG
Mounting
Desktop
=======================================================================================================================
Package includes:
-
1 x eight Channel Network Video Recorder
-
1 x USB mouse
-
1 x 2TB Hard disk (It was inside the NVR when delivery)
-
4 x 2.0MP 1080P Network Wired IP Camera with Bracket
-
4 x Camera Power adapter
-
4 x CD manual
-
4 x Screws package
=======================================================================================================================
